EMIA‑Pro
Carbon/Sulfur Analyzer
The EMIA‑Pro Carbon/Sulfur Analyzer provides exceptional accuracy, streamlined maintenance, and user‑friendly software enhancements that enable efficient measurements. Its reduced cycle time helps accelerate development and manufacturing speed.
Why Choose EMIA‑Pro
- Exceptional accuracy with NDIR detection
- Wide range: Carbon 1.6 ppm–6.0%, Sulfur 2 ppm–1.0%
- Unique CO detector for diverse inorganic materials
- Up to 200 measurements without cleaning
- Modular upgrades: Purifier, Auto Sampler, Halogen Trap
- Intuitive software with self‑diagnostics and navigators
Key Advantages of EMIA‑Pro
1.
Ultra‑High Precision
Optimal elemental quantification
2.
Extended Maintenance
Reduced downtime with auto‑cleaning
3.
Rapid Throughput
Accelerates workflow
4.
Modular Expandability
Scalable capacity
Applications of EMIA‑Pro
Lithium‑ion Battery Materials Analysis
Carbon/Sulfur quantification for performance optimization.
Fuel Cell Material Validation
Ensuring purity in fuel cell catalysts.
Ceramic Composition Control
Monitoring elemental consistency in advanced ceramics.
Semiconductor Purity Testing
Detects trace elements in silicon and GaN.
Technical Specifications of EMIA‑Pro
| Contents | EMIA-Pro | |
|---|---|---|
| Required sample amount | 1g ± 0.1g | |
| Typical Meas. time | 70 seconds/cycle | |
| Carbon | Meas. Range (m/m) | 1.6 ppm - 6.0% |
| Blank accuracy | σn-1 ≦ 0.8 ppm | |
| Sulfur | Meas. Range (m/m) | 2.0 ppm - 1.0% |
| Blank accuracy | σn-1 ≦ 1.0 ppm | |
| Sample meas. Accuracy | Carbon | σn-1 ≦ 2.0 ppm or RSD≦1.0% |
| Sulfur | σn-1 ≦ 2.0 ppm or RSD≦1.5% | |
| Utility | Carrier gas | Oxygen (Purity; 99.5%, Pressure; 0.30-0.33MPa) |
| Operation gas | Nitrogen (Purity; 99.5%, Pressure; 0.35-0.38MPa) | |
| Power | 200/220/240V, 50/60Hz, 5kVA | |
| Dimensions | Main unit* | 500(W) x 725(D) x 710(H) mm |
| Mass | Main unit | approximately 134 kg |
| Data processing and operation | USB data communication with PC Windows 8.1 Touch panel or Key board and mouse operation | |
| Model name | EMIA-20P: Carbon/Sulfur EMIA-21P: Carbon EMIA-22P: Sulfur | |
Note) "ppm" is equal to mg/kg.
*Except piping parts, projection parts (D:79mm) and flow meter on the back side.
Schematics
Accessories
Crucible Pre-heating Unit
The crucible pre-heating unit; FK-100 with automatic transportation function to heat a ceramic cruible at 1100 degree in 10min. before analysis.
Autosampler
Automation crucible loading and disposing unit. Up to 20 pcs of crucible are available to be set. Click here for more information of automation options.
Consumables
Ceramic crucible
Low carbon blank and high dimension tolerance for high precision analysis.
Accelerators
High-purity materials which support stable analysis: Tungsten(W), Tin(Sn), Copper(Cu), Iron(Fe)
